| Place of Origin: | Wuxi ,China |
|---|---|
| Brand Name: | NKBALER |
| Certification: | CE,ISO |
| Model Number: | NKW125Q |
| Minimum Order Quantity: | 1 |
| Packaging Details: | Wooden case |
| Delivery Time: | 10-30 days |
| Payment Terms: | T/T |
| Supply Ability: | 200-300 SETS PER YEAR |
Hydraulic Baler for Cardboard is equipment specially designed for compressing and baling cardboard and other recyclable materials. This machine uses a hydraulic system to generate strong pressure to compact and bundle materials into blocks to reduce their volume and facilitate storage and transportation.
| Item | Name | Parameter |
|
mainframe parameter |
Bale size | 1100mm(W)×1100mm(H)×～1600mm(L) |
| Material type | Fiber Scrap Kraft paper, Carton, Cardboard ,Soft Film, | |
| Material density | 500～600Kg/m3(Moisture12-15%) | |
| Feed opening size | 2000mm×1100mm | |
| Output | 9-12tons/hour | |
| Main motor power | 37.5KW+11KW | |
| Capacity | 10-12Ton12-15Ton | |
| Main cylinder | YG220/160-2900 | |
| Main cylinder force | 125T | |
| Max. system working force | 21MPa | |
| Mainframe weight(T) | About 21 tons | |
| Mainframe size | About 11×2.3×2.9M(L×W×H) | |
| Tie wire line | 4 line φ2.75～φ3.0mm3 iron wire | |
| Pressure time | ≤30S/ (go and back) | |
| Chain conveyor technology | Model | NK-III |
| Conveyor weight | About 5 tons | |
| Conveyor size | 2000*12000MM | |
| Conveyor motor | 7.5KW | |
| Cool tower | Cool tower motor | 0.75KW(water Pump)+0.25(Fan) |
Here are some key features:
1. Efficient compression: The hydraulic baler can provide high pressure to ensure that the cardboard is compressed quickly and efficiently.
2. Automated operation: Many hydraulic balers are equipped with automatic cycle control systems, including automatic compression, bundling and bale unloading functions.
3. Safety performance: These devices usually have necessary safety features, such as emergency stop buttons, safety light curtains or protective nets, to ensure the safety of operators.
4. Adjustability: According to different needs, users can usually adjust the packaging pressure and bale size.
5. Economical and energy-saving: Hydraulic systems are generally more energy-efficient and have lower maintenance costs than other types of compression systems.
6. Durability: High-quality hydraulic balers are designed to withstand long periods of continuous use and are easy to maintain.
When selecting a hydraulic baler, factors to consider include the type and size of materials handled, the required baling efficiency, and your budget. Hydraulic balers are ideal for use at scrap recycling depots, paper mills, packaging companies and other industries that need to handle large amounts of cardboard material.
Please note that the above description is based on general hydraulic baler characteristics and specific product performance and functionality may vary. If you need to know more about the technical details of a specific model, it is recommended to consult the manufacturer or consult relevant technical information.
