NKW160Q PP Films Baling Press Machine
  • NKW160Q PP Films Baling Press Machine

NKW160Q PP Films Baling Press Machine

NKW160Q PP Films Baling Press Machine is a mechanical equipment for compressing and packaging films. It is widely used in food,beverage,pharmaceutical and other industries. It compresses,packs and bundles films in an automated way,perfectly solving the problem of storing waste items.The NKW160Q PP Films Baling Press Machine is a high-performance, fully automatic horizontal baler specifically engineered for processing OCC paper, newspapers, cardboard, and soft film materials. This versatile machine transforms bulky paper waste into compact, high-density bales—optimizing storage, reducing transportation costs, and streamlining recycling operations.

📝
Description

NKW160Q PP Films Baling Press Machine is a mechanical equipment for compressing and packaging films. It is widely used in food,beverage,pharmaceutical and other industries. It compresses,packs and bundles films in an automated way,perfectly solving the problem of storing waste items, this baling system delivers exceptional performance with:Rapid Processing: Capable of completing 8 compact bales per hour;Energy Efficiency: Consumes only 2kWh per bale cycle;High Compression: Optimizes storage and transportation space;Automated Operation: Minimizes labor requirements.

Utilizing an advanced hydraulic transmission system with dual-cylinder operation, the NKW160Q delivers a powerful 150T main cylinder force at a maximum system working pressure of 30.5 MPa. Its sophisticated PLC control system, complete with photoelectric sensors and automatic error detection, ensures precise feeding, compression, and bale ejection. The adjustable bale parameters allow operators to customize bale size (approximately 1100 × 1100 × up to 1600 mm) and achieve a material density of 600–700 kg/m³.


📝
Specs

 ModelNKW160Q1NKW160Q2
 Hydraulic power1600KN1600KN
 Cylinder sizeØ280Ø280
 Bale size(W*H)1100*1100mm1100*1250mm
  Bale weight1100-1300Kg1200-1400Kg
  Capability10-12T/H12-15T/H
  Material density450-500KG/m^3450-500KG/m^3
  Bale line4-5Line 4-5Line
  Power37.5KW+11KW45KW+11KW
  Strapping wayAutomaticAutomatic
  Feeding Deviceconveyorconveyor


📊
Video

📅
Sales Terms & Conditions

Place of Origin:Made in China

Brand Name:NKBALER

Certification:CE,ISO

Model Number:NKW160Q

Minimum Order Quantity:1

Delivery Time:35-40 days

Payment Terms:40% deposit by T/T,60% before delivery

Supply Ability:150-200 SETS PER YEAR


High-Quality Components for Durability & Performance

Hydraulic System: Japanese-brand components (manufactured in China)

Motors & Pumps: Wannan – high-torque, energy-efficient motor

Seals: Hallite (England) ensure leak-free hydraulics

Steel Frame: Bao Steel high-strength structure

Electrical Components: DELIXI (German brand, China production)

PLC System: Mitsubishi for intelligent automation

Bearings: NSK smooth, long-life operation

Tubing & Pipes: High-quality China-made hydraulic lines
