NKW200Q Solid Recovered Fuel (SRF) Baler
  • NKW200Q Solid Recovered Fuel (SRF) Baler

NKW200Q Solid Recovered Fuel (SRF) Baler

NKW200Q SRF balers are device that compresses solid trash into blocks or bundles for easier storage and transport. This equipment is widely used in a range of industries, such as manufacturing, construction, and agriculture, to handle solid waste created during production.

📝
Description

NKW200Q SRF balers, a heavy-duty compaction system designed to process solid waste into dense, uniform bales for optimized storage and transportation. This industrial baler serves multiple sectors including manufacturing, construction, and agricultural operations, effectively managing production waste streams.The NKW200Q SRF Baler is a fully automatic horizontal baling machine designed to convert various waste materials—such as scrap kraft paper, newspapers, cardboard, soft film, and plastics—into dense, uniform bales. SRF stands for Solid Recovered Fuel, which is a type of fuel produced from processed waste materials and is used as an alternative energy source in cement kilns, power plants, and industrial boilers.

Engineered for high-volume recycling centers and waste-to-energy facilities, the NKW200Q Solid Recovered Fuel (SRF) Baler employs a robust hydraulic transmission system with dual-cylinder operation. It delivers a powerful 200T main cylinder force at a maximum working pressure of 30.5 MPa, enabling the machine to process 25–30 tons of material per hour. The machine produces bales with dimensions of approximately 1100 mm (W) × 1100 mm (H) × up to 1800 mm (L) and a material density of 650–700 kg/m³—ensuring that the output meets the stringent requirements for SRF production.


📝
Specs

 ModelNKW200Q1NKW200Q2
 Hydraulic power2000KN2000KN
 Cylinder sizeØ320Ø320
 Bale size(W*H)1100*1100mm1100*1250mm
  Bale weight1200-1600Kg1300-1600Kg
  Capability28-30T/H32-35T/H
  Material density500-600KG/m^3500-600KG/m^3
  Bale line5Line 5Line
  Power45KW*2+15KW45KW*2+15KW
  Strapping wayAutomaticAutomatic


📊
Video

📅
Sales Terms & Conditions

Place of Origin:Made in China

Brand Name:NKBALER

Certification:CE,ISO

Model Number:NKW200Q

Minimum Order Quantity:1

Delivery Time:35-40 days

Payment Terms:40% deposit by T/T,60% before delivery

Supply Ability:200-300 SETS PER YEAR

Integrated with an advanced PLC control system and photoelectric sensors, the NKW200Q automates the feeding, compression, and bale ejection processes. Its adjustable bale parameters and automatic strapping device ensure consistent bale quality and enhance operational efficiency. Additionally, an NK-III chain conveyor (2000 mm × 14,000 mm, 7.5 kW motor) facilitates continuous material flow, while an oil chiller with fan cooling maintains optimal operating temperatures.
